Junction Box BOXX H2 (EM134)

Item no. 905005

905005 / EM134 BOXX H2
4
Product description
Product description
For quick and safe installation of all current cables indoors and in protected outdoor areas.
  • Verband der Elektrotechnik, Elektronik und Informationstechnik
  • Communautés Européennes, EC declaration of conformity according to EC directives
  • Polypropylene
  • Halogen-free
  • UV-resistant
Technical data

Technical data

Colour Light grey; RAL 7035
Cover fastening Locking
Diameter 80 mm
Dimension Ø80x51
Entry from rear yes
Equipment Without
Expandable no
For Ex zone dust Without
For Ex zone gas Without
Halogen-free yes
Maintain electrical functions Without
Material Polypropylene
Max. Conductor cross-section 2,5 mm²
Measured insulation voltage Vi 500 V
Mounting type Wall/ceiling mounting
No. of entries 4
Permitted temperature range, max. 60 °C
Permitted temperature range, min. -5 °C
Protection rating IP65
Protection rating IK code IK08
Shape Round
Transparent lid no
Type of entry Cable
Type of housing penetration Cuttable stepped membrane
Version, small distributor cover Closed
Weatherproof no
With screening no
All types

All types

Types No. of entries Item no. Quantity SSU
EM134 BOXX H2 4 905005
5 piece
Downloads

Download

Download

EU declaration of conformity EM134 BOXX H2 / 905005 , 0.13MB , pdf
